FF46-1 FF46-2 Teflon high temperature wire AF200 cable 200°c heat resistant wire FEP Technical Information:
Color: red-black-yellow-green-blue-white-purple-brown-orange-grey-transparent-yellow-green
FF46-1 FF46-2 Teflon high temperature wire AF200 cable 200°c heat resistant wire FEP common size
|
size mm2 |
conductor size |
conductor diameter (mm) |
insulation thickness (mm) |
outer diameter (mm) |
|
0.14 |
7/0.16 |
0.48 |
0.25 |
1.00±0.05 |
|
0.22 |
7/0.2 |
0.60 |
0.25 |
1.10±0.05 |
|
0.25 |
7/0.23 |
0.69 |
0.25 |
1.20±0.05 |
|
0.5 |
19/0.18 |
0.90 |
0.25 |
1.40±0.1 |
|
0.75 |
19/0.23 |
1.15 |
0.25 |
1.65±0.1 |
|
1.0 |
19/0.26 |
1.30 |
0.25 |
1.90±0.1 |
|
1.5 |
19/0.32 |
1.60 |
0.30 |
2.20±0.2 |
|
2.0 |
19/0.37 |
1.85 |
0.30 |
2.45±0.2 |
|
2.5 |
19/0.41 |
2.05 |
0.40 |
2.85±0.2 |
|
4.0 |
37/0.37 |
2.59 |
0.40 |
3.40±0.3 |
|
6.0 |
37/0.45 |
3.15 |
0.50 |
4.15±0.3 |
|
10.0 |
133/0.32 |
4.68 |
0.50 |
5.70±0.5 |
|
16.0 |
133/0.39 |
5.70 |
0.60 |
6.90±0.5 |
|
25.0 |
196/0.4 |
7.10 |
0.60 |
8.30±0.5 |
|
35.0 |
494/0.3 |
8.45 |
0.70 |
9.90±0.8 |
|
50.0 |
396/0.4 |
10.08 |
0.80 |
11.70±0.8 |
FF46-1 FF46-2 Teflon high temperature wire AF200 cable 200°c heat resistant wire FEP has excellent fire resistance, non-combustibility, acid, alkali, corrosion resistance, strong oil resistance, waterproof and moisture-proof. Suitable for use in high temperature environments below AC 600V, such as instrumentation, aerospace, electric power smelting, petroleum, chemical industry, ships, vehicles, food machinery, household appliances, drying rooms, etc.
